2018 China Top Crane Single Girder Electric Hoist With Remote Control

Payment Terms: TT or LC

Ref Price : 2600-4000 USD/TON

Supply Capability : 3000 TON

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Quick Details

  • Feature:
    Bridge Crane, Floating Crane
  • Condition:
    New
  • Rated Loading Capacity:
    5 ton
  • Rated Lifting Moment:
    50kn
  • Max. Lifting Load:
    5 ton
  • Max. Lifting Height:
    30m
  • Model Number:
    LX
  • Certification:
    GB/T 28001-2001,OHSAS18001:1999
  • Working system::
    A3~A5




China Top Crane Single Girder Electric Hoist With Remote Control 5Ton



LDP type top running overhead crane, is excellent for low runway workshop.The hoist runs on top of the beam, and gives better lift height than standard single girder crane and provide substantial savings in eliminating the need for both purchase and installation of the crane rail.two operational methods - ground or cabin (open or closed type). The capacity:1T, 2T, 3T, 5T,10T,16T,20T,span is from 7.5m to 22.5m,optional voltage is 380V 50Hz three-phase


Product detail:

2018 China Top Crane Single Girder Overhead With Electric Hoist


Lifting Capacity

T

1t

2t

3t

5t

10t

16t

20t

Span

m

7.5~22.5m

7.5~31.5

Speed

Lifting

MD1 hoist

m/min

8/0.8 (7/0.7)

3.5/0.35

CD1 hoist

8 (7)

3.5

Traveling of electric hoist

20

20

Traveling of crane

20/30

20/30

Wheel diameter

Φ270

Φ370

Width of trail

37~70mm

37~70mm

Operational Model

Remote control; Ground handle

Remote control; Ground handle

Working Duty

A3

Power Supply

Three-phase A.C. 380V, 50Hz

Three-phase A.C. 380V, 50Hz


















  • Mechanism Parts

1. Single girder, made by the high quality I steel and high quality U-shapped slot into composition

2. Material Q235B or Q345B(similar as Fe37 or Fe52)

3. End beam is welded with rectangular tubes or good steel

4. Main girders connected with bolts

5. Crane traveling use respective drive

6. QS trinity-drive system or traditional drive by motor and reducer

7. Assembly and adjustment is rapid, simple

8. Use LD single girder special wheel, light and strong versatility


Crane-Spare Parts 1.jpg


  • Electric Hoist

1. Lifting motor: Tapered rotor three-phase asynchronous braking motors
2. Reducer: Three-level dead axle helical gear rotating body, Gear and the axle made by alloy steel after heat treatment, high intensity

3. Rope drum: Made of cast iron or seamless steel tube, light weight, transmit the dynamic force by splines.

4. Steel wire rope: It uses GB1102-74(6*37+1) hoist steel wire rope which is durable in use

5. Forge with special steel: thrust ball bearing connect with casing through hook and beam to make the hook operate freely.


Crane-Spare Parts 4.jpg


  • Electric Equipments

1. Trolley conductor or angle steel conductor power supply

2. Hoist and crane separately control, move separately or together

3. Flat cable or special cable power supply for electric hoist

4. Galvanize slide and cable trolley, smoothly moving, appearance is aesthetics

5. Electrical non-contact speed regulation control module

6. Operation, hoisting, the point start are very smoothly

7. Power leading has both methods of current collector and flexable cable
