China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

Please enter your email.

cancel

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

Payment Terms: TT or LC

Ref Price : 28000-300000 USD/TON

Supply Capability : 200 TON

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Qulck Details

  • Place of Origin:
    Henan, China (Mainland)
  • Brand Name:
    Weihua
  • Model Number:
    GTJZ Battery Power Self Propelled Electric Hydraulic Scissor Lift
  • Lift Mechanism:
    Scissor Lift
  • Lift Drive / Actuation:
    Electric Motor
  • Power:
    2.2kw
  • Rated Loading Capacity:
    300kg
  • Min. Lifting Height:
    0.5m
  • Max. Lifting Height:
    14m
  • Table Size:
    1200*800*55mm
  • Overall Dimensions:
    1200*800*1700mm---2500*1350*2300mm
  • Weight:
    135kg
  • Warranty:
    1 Year
  • After-sales Service Provided:
    Engineers available to service machinery overseas
  • Lift packaged:
    By standard exporting packaged Product name: Battery Power Self Propelled Electric Hydraulic Sciss
Product Detail
  • China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift
    1. Electrical parts and hoist are packed by strong plywood box, to prevent the rain soaked.
    2. Main beam, end beam, platform railing and others are packed in plastic woven cloth, to prevent corrosion in seawater.

  • Delivery Time

  • Within 30days





It is ideal lift platform for aerial maintain and clean, used indoor or outdoor. With AC driven system.

Electric lift makeslow noise and no emission when working. 90-degree steering can run in both high

and low speeds, The scissor lift can be easily and flexibly operated in crowded working conditions

such as construction site,elevator,and narrow corridor. Liftdown, turning,forward and backward movements

can be easily operated by single person.

Lift height: 4m - 16m

Load capacity: 100kg - 3000kg

Platform size and power: as your requirement

Product name:Movable hydraulic scissor lifting platform

Model:SJY




China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

Material of scissor part

Made of high strength manganese steel tubes,never deformed.

Emergency decline

Make the platform down under emergency situation.

No trace solid tire

The small solid rubber wheels moves slightly, and it has no any damage to the floor.And it can make 90 degree turn in situation,

run in both high and low speeds, and be used even in small space.

Traggable engine tray

Chassis can be swing out, which facilitate the maintenance, inspection and replacement.

Brake release

manual loweing valve design make it easy to realse the machine and let it down automatically when emergency

happens or when the machine is out of power.

Removable platform control panel (DTC controller)

the joystick on the platform is portable and removable, we use DTC controlling system to guarantee the stability of the

whole machine movements, including lifting, lowering, steering, forward, backward etc



Application



It is widely used for aerial installation and maintenance of the working sites without power supply

and with smooth working grounds, such as hotels, grand hall, sport stadium, large factory, workshops,

warehouse, granary,bus/railway stations, hotels,airports, gas station and aerial pipeline.

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift


Feature



1)Self propelled Scissor Lifts does not need any outriggers, one man operates on the working platforms.

2)Moving forward,turning around and lifting up are easily operated.

Performances

Reliability and Versatility ,Enhance Effiency

Excellent Mobility Compact body can easily pass through single and double channel doorway,using non-marking solid tire.
Special Locations Features of low noises is perfectly suitable for the noise-sensitive environment,such as office buildings,shopping malls, hotels,schools,ect.
Compact and Flexible

Most models are equipped with zero inside turning radius capacity, can be easily and flexibly operated in crowded working conditions such as construction site ,elevator,and narrow corridor.Lift-up,lift-down,turning,forward and backward movements can be easily operated by one person.


More self-propelled Hydraulic Scissor Lift Platform

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

Shipment pictures

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

 Company Information

Henan WEIHUA Heavy Machinery Co., Ltd belongs to WEIHUA Group Co., Ltd, which is founded in 1988,

has devoted to design, manufacturing, sales, installation of industrial cranes, harbor cranes, mineral machinery,

mobile cranes, etc., with whole-process and integrated solutions to engineering design and construction,

technical services and consulting.

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

Overview of Factory

 China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift



Certifications

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift

Business Communication

China Top Design 4-14m Battery Power Self Propelled Electric Hydraulic Scissor Lift







   Henan Weihua Special Vehicle Co.,Ltd.(referred to as HenanWei Te) By the Weihua Group and Singapore Terra Lite joint venture to creat a registed capital of 100 million yuan, located in Henan Province Changyuan Country Automobile Industrial Park.

Since its inception, the company has been committed to industrial vehicles, enviromental equipment, special vehicles, high-altitude operations and lifting equipment R & D and manufaturing. Leading products and service in urban construction, urban management, urban maintenance and moden logistic and other important areas.
