Bridge Bucket-wheel Reclaimer from China

Payment Terms: TT or LC

Ref Price : 1500-50000 USD/SET

Supply Capability : 10000 SET

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Qulck Details

  • Product Name:
    Bridge-type Bucket-wheel Reclaimer
  • Capacity:
    300t/h, 2500t/h
  • Particle Size:
    0-300mm

Description


The bridge-type bucket-wheel reclaimer is suitable for the stock yards in the iron & steel and industries because it can satisfy the mixing reclaiming operation requirements of coal, ore concentrate, ore fines and other bulk materials. The bridge-type blending reclaimer includes bridge-type bucket-wheel reclaimer, bridge-type scrapper reclaimer and bridge-type roller reclaimer.



Features:



1. It can save investments with low energy consumption, low operation costs and high production efficiency.


2. It has rational structure and favorable stability.

3. The bridge-type mixing reclaimer has good mixing effect, large reclaiming capacity, high production efficiency and strong materials adaptability.

4. It has simple operation, safety and reliability, therefore, it is easy to realize the automation.


Specification


Equipment Model Unit

QHL

650. 32

QHL

1000.35

QHL

1800.37

QHL

2500.45

QHG

150. 22.6

QHG

900. 46

QHG

1200.42

QLG

1500.40

QLG

300.10

Name

Bridge-type bucket-wheel

reclaimer

Bridge-type scrapper

reclaimer

Side cantilever

rotary stacker

Production Capacity t/h 650 1000 1800 2500 1000 1800 2200 1500 300
Material characteristics Applicable materials  Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials

Density t/m³ 0.5~2.5
Particle Size mm 0~300
Traveling speed Work m/min 0~25 infinite speed variation 0.004~0.04 0.05 0.027
Dispatching vehicle  m/min 11.55 12
Rail gauge m 32 35 37 45 22.6 46 42 40 10
Maximum wheel load KN 250/300
Recommended steel track P50/Q80
Power supply mode  Cable drum/safety sliding contact line
Contact mode  Cable drum/safety sliding contact line/wireless
Control mode  PLC program control, manual and single action


Weihua Group, a leading crane manufacturing company in China, was Founded in 1988. We has been committed to heavy machinery researching and marketing.


The main product covers shipbuilding gantry crane, lifting machinery, port container crane, heavy mining machinery and construction machinery, etc. The whole coverage of Weihua Group is 3,420,000 m2 with 6,800 employees.


Weihua adheres to scientific and technological innovation and owns a 600-people R&D team, 494 patents, CNAS laboratory, etc. For the cranes, Weihua have made many breakthroughs which include anti-sway crane system, CNC high precision positioning crane system, self-climbing crane for wind power maintenance and so on.


In recent years, Weihua cranes have been employed to serve China's Aerospace Engineering projects such as launching of Shenzhou spacecraft, Long March carrier rockets and Tiangong space laboratory. You can also find Weihua products in the fields of manufacturing, metallurgy, nuclear power, railway,port, petrochemical and wind power.


Weihua products also find its places in the global markets and won much praise from108 countries like America, Japan, Russia, Singapore, Korea, Thailand, Malaysia, Mexico, etc.


Our success comes from customers' success. Welcome to Weihua.
