China Mobile scissor lift platform/indoor and outdoor 10m aerial work Hydraulic Lift Platform

Payment Terms: TT or LC

Ref Price : 1000-3000 USD/SET

Supply Capability : 120 SET

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Quick Details

  • Product Name：
    Indoor and outdoor 10m aerial work Hydraulic Lift Platform
  • Walking method：
    Electric assist or manual push and pull
  • application：
    Plant work at height, outdoor aerial work
  • Power：
    380V/2.2KW
  • Overall Dimensions：
    2200*1350*1550mm
  • After-sales Service Provided：
    Online support
  • wheel：
    Four
  • control method：
    Control panel or control box
  • operating：
    Manual, video
  • Lift Mechanism：
    Scissor Lift
  • Table Size：
    2100*1200mm
  • Weight：
    1400kg
  • Brand Name：
    WeiHua
  • Place of Origin：
    Tianjin, China (Mainland)

China Mobile scissor lift platform description:


The lifting platform is a multifunctional lifting and handling machinery that can be divided into fixed and mobile.It refers to vertical conveying equipment in logistics systems, such as factories and automated warehouses. The lifting platform is a lifting device that transports people or objects vertically. The lifting platform is often equipped with various plane conveying equipment as connecting devices for different height conveyor lines.It has the advantages of electric start, self-supporting leg, simple operation, light weight, self-propelled, large working surface, and 360-degree free rotation for high-altitude operations across obstacles.


Part of  mobile scissor lift platform specification:


Type model Lifting height(m) Load(kg) Table size(mm) Dimensions(mm) power power(kg)
Mobile scissor lift platform HTSJY0.5-6 6 500 2100*830 2250*950*1200 380V/1.5KW 850
Mobile scissor lift platform HTSJY0.5-8 8 500 2100*930 2250*1060*1380 380V/1.5KW 950
Mobile scissor lift platform HTSJY0.5-10 10 500 2100*1200 2200*1350*1550 380V/2.2KW 1400
Mobile scissor lift platform HTSJY0.5-12 12 500 2550*1530 2800*1700*1750 380V/3KW 2200
Mobile scissor lift platform HTSJY0.5-14 14 500 2810*1500 3070*1730*1850 380V/3KW 2400
Mobile scissor lift platform HTSJY0.5-16 16 500 2810*1600 3070*1810*2080 380V/4KW 3500
Mobile scissor lift platform HTSJY0.5-18 18 500 3070*1600 3350*1810*2080 380V/4KW 3900


Application of Scissor aerial work platform:


Scissor aerial work platform is an equipment used widely in aerial work. Its scissor structure make the lifting station has high stability, large platform and a strength carrying capacity. Therefore, it has a greater range of operations at high altitude, and suitable for many people simultaneously. It enables high-altitude operations more efficient, safer and protected.



10m aerial work Hydraulic Lift Platform Features:


1. Widely applicable, it is suitable for factory shop, square, lobby, airport, park and other high-attitude operations place.
2. Adaptability, it can be used in harsh environments and general explosion proof place.
3. High safety, it is equip the up-down double control button with low voltage and one-touch emergency stop and lowering device, to improve the safety of equipment.
4. Stability structural , carrying capacity, stable lifting, easy maintenance.


FAQ:


Q1: Are you trading company or manufacturer?

A: We are manufacturer.



Q2: Do you provide scissor lift platform samples? Is it free or extra?

A: Yes, we could offer the scissor lift platform samples for free charge but do not pay the cost of freight



Q3: What is your terms of payment?

A: L/C, T/T and so on



Q4: How do you make our business long-term and good relationship?

1.Good service is our basic principle for every customers.

2.Our high quality and competitive price are the most important factors to maintain long-term and good relation -ship with our customers.


IF you want to buy our scissor lift platform or want to know more about aerial work Hydraulic Lift Platform,you can send us a message to get answers and quality service.

Weihua Group, a leading crane manufacturing company in China, was Founded in 1988. We has been committed to heavy machinery researching and marketing.


The main product covers shipbuilding gantry crane, lifting machinery, port container crane, heavy mining machinery and construction machinery, etc. The whole coverage of Weihua Group is 3,420,000 m2 with 6,800 employees.


Weihua adheres to scientific and technological innovation and owns a 600-people R&D team, 494 patents, CNAS laboratory, etc. For the cranes, Weihua have made many breakthroughs which include anti-sway crane system, CNC high precision positioning crane system, self-climbing crane for wind power maintenance and so on.


In recent years, Weihua cranes have been employed to serve China's Aerospace Engineering projects such as launching of Shenzhou spacecraft, Long March carrier rockets and Tiangong space laboratory. You can also find Weihua products in the fields of manufacturing, metallurgy, nuclear power, railway,port, petrochemical and wind power.


Weihua products also find its places in the global markets and won much praise from108 countries like America, Japan, Russia, Singapore, Korea, Thailand, Malaysia, Mexico, etc.


Our success comes from customers' success. Welcome to Weihua.
