Chinese Manufacturer Weihua Single Girder Light 1ton Gantry Crane Price

Payment Terms: TT or LC

Ref Price : 1000-10000 USD/SET

Supply Capability : 5000 SET

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Qulck Details

  • Main Girder Form:
    Single Girder
  • Crane Feature:
    Electric Single Girder Gantry Crane
  • Lifting Mechanism:
    Electric Hoist or Trolley
  • Power Source:
    3 Phase 380V, 50Hz or Customized
  • Color:
    Customized
  • Language:
    English, Russian, Spanish, French
  • Main Electrical Parts:
    Schneider
  • Working Class:
    A4-A7
  • Trademark:
    WEIHUA CRANE
  • Transport Package:
    Customized
  • Specification:
    As the actual size
  • Origin:
    Henan, China
  • HS Code:
    8426193000
  • Model NO.:
    Single girder light gantry crane

Introduction

Brief Description
lifting weight: 5ton~50ton
Lifting Height: 10m~12m
span: 18m~35m
Product Description
Releated single beam gantry cranes 15 ton

Features:
1. high working effiency;
2. smooth movement &comfortable operation;
3. convenient maintenance & aesthetic painting;
4. light deadweight, light wheel load and reliable performance;
5. customized: design and manufacture according to your request.
Mechanism:
1. High quality carbon steel Q235B and Q345B;
2. connected by high strength screws;
3. Welding seams are tested by X-ray and ultrasound;
4. Compact structure, small volume;
5. Compact reducer motor drive, step less control, hardened gears and safety disc brake;
6. Good operation performance, step less speed regulating and running smoothly;
7. Painting high quality epoxy zinc-rich primer, and the thickness of oil film is 140μm;

Electric System:
1. Control panel protection degree is IP54;
2. Reasonable components installation, convenient for check and maintenance;
Safety Protection Devices:
Overload limiter, limit switch, interlocking protection devices, buffer, track sweep plate, bus bar protection board, anti-collision device, main disconnecting switch, emergency stop system and motor overload protection.


Specification

Lifting capacity

(t)



Span

(m)



Lifting height

(m)



Work duty



Main lifting

(m/min)



Deputylifting

(m/min)



Trolley travelling

(m/min)



Crane travelling

(m/min)



Power

(KW)



Rail type



5



18~22



10



A5



9.2



--



36.6



46.3



27.8



43Kg/m



26~35



11



40.1



36.8



10



18~22



10



8.5



--



39.7



39.6



38



26~35



11



40.1



47



16/3.2



18~26



10



7.9



11.2



39.5



40.1



64.6



30~35



11



47.1



75.6



20/5



18~26



10



7.1



9.2



39.3



40.1



67.3



30~35



11



47.1



78.3



32/5



18~22



10



6.3



9.2



38.6



48.2



85.5



QU80



26~35



11



38.6



93.5



50/10



18~26



10



5.9



8.5



38.5



39.7



141



30~35



12


Visiting


Weihua Group, a leading crane manufacturing company in China, was Founded in 1988. We has been committed to heavy machinery researching and marketing.


The main product covers shipbuilding gantry crane, lifting machinery, port container crane, heavy mining machinery and construction machinery, etc. The whole coverage of Weihua Group is 3,420,000 m2 with 6,800 employees.


Weihua adheres to scientific and technological innovation and owns a 600-people R&D team, 494 patents, CNAS laboratory, etc. For the cranes, Weihua have made many breakthroughs which include anti-sway crane system, CNC high precision positioning crane system, self-climbing crane for wind power maintenance and so on.


In recent years, Weihua cranes have been employed to serve China's Aerospace Engineering projects such as launching of Shenzhou spacecraft, Long March carrier rockets and Tiangong space laboratory. You can also find Weihua products in the fields of manufacturing, metallurgy, nuclear power, railway,port, petrochemical and wind power.


Weihua products also find its places in the global markets and won much praise from108 countries like America, Japan, Russia, Singapore, Korea, Thailand, Malaysia, Mexico, etc.


Our success comes from customers' success. Welcome to Weihua.
