DC Powered Self-propelled Electric Aerial Scissor Lift Platform for 6-12m

Payment Terms: TT or LC

Ref Price : 1-10 USD/TON

Supply Capability : 10000 TON

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Qulck Details

  • Place of Origin:
    Henan, China (Mainland)
  • Brand Name:
    Weihua
  • Model Number:
    Stationary Scissor Lift Table
  • Lift Mechanism:
    Scissor Lift
  • Lift Drive / Actuation:
    Electric Motor
  • Min. Lifting Height:
    4m
  • Max. Lifting Height:
    16m
  • Warranty:
    12 Months
  • Application:
    Aerial Work
  • Voltage:
    Local Voltage
  • Color:
    Design
  • Product name:
    Movable Hydraulic Scissor Lift Platform
  • Type:
    Scissor Lift
  • Material:
    High-duty Steel Structure
  • Feature:
    Superior Performance

Product Detail:

Electric scissor lift platforms are used where more workspace and lifting capability is required. With working heights up to 66ft and capabilities up to 3000kg ( could be designed by requiry ), they are designed to provide larger platform work areas and generally to allow heavier loads than boom lift.

WEIHUA Brand 8m 10m  Movable Electric Hydraulic Scissor Lift Platform

Features

1. Vertical raising of platform

2. Convenient operation (can be controlled both on the platform and the ground)

3. Horizontal extension of deck(customized)

4. Scissor lifts are available in various electric and battery

Model& Advantages

1.Electric Powered Models (220v or 380v etc)

2. Indoor/outdoor Usage

3. No noise or air pollution

4. Longer usage time

5. High working capacity, easily pushed around, most spacious platforms for several people to work

6. High strength steel structures smoothly lift up and drop down, easily operated, few faults

7. Moving method: 4 wheel and 2wheel types are optional, it can be pneumatic rubber tires, solid rubber tires or polyurethane tires

8. Power sources: local power available at the working sites(110V,220V,380V,415V)

9. Lifting height: 4m,6m,8m,10m,12m,14m,16m,18m(could be designed)

WEIHUA Brand 8m 10m  Movable Electric Hydraulic Scissor Lift Platform


Specification:




Model

Platform height

(m)

Capacity

(kg)

Platform size

(mm)

Closing size

(mm)

Dead weight

(kg)

Standard motor power

Power source

SJY0.3-4

4

300

1700*1080

1820*1400*1180

660

2.2kw

380V 50hz 3phase

SJY0.3-6

6

300

1700*1080

1820*1400*1280

750

SJY0.3-8

8

300

1800*1060

1900*1380*1460

850

SJY1.0-8

8

1000

1940*1300

1920*1630*1980

1050

SJY0.3-10

10

300

1920*1200

2040*1580*1660

1300

SJY1.0-10

10

1000

1920*1300

2060*1630*1980

1500

SJY0.3-12

12

300

1370*1300

2510*1630*1980

1420

SJY1.0-12

12

1000

2400*1340

2530*1630*2000

1700

3.0kw

SJY0.3-14

14

300

2650*1300

2800*1660*1980

1800

2.2kw

SJY0.3-16

16

300

2650*1340

2800*1600*2130

2800

3.0kw
