Foam glass board material for industry insulation

Payment Terms: TT or LC

Ref Price : 1-10 USD/CUBIC METERS

Supply Capability : 10000 TON

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Qulck Details

  • Place of Origin:
    China (Mainland)
  • Brand Name:
    wanmaide
  • Product name:
    foam glass panel
  • Size:
    600mm x 480mm x (30~150)mm
  • Color:
    Black, grey
  • Certificate:
    CE , MSDS , ISO , etc.


Foam glass is a new inorganic thermal insulation material..Mainly made from glass powder and well reserves the chemical stability of inorganic glass, foam glass thereby possess the following features of low density, low thermal conductivity, non- aging, high durability.

1 Foam glass tube has the function of moistureproof, fireproof , anticorrosion, and the advantage of long - term use. Therefore, foam glass tubes are favored by users in strict environments such as adiabatic, deep cold, underground, outdoor, inflammable, damp and chemical erosion. Foam glass tube can be used for thermal equipment, pipes, containers and refrigerating machine insulation, storage tank.

2 Foam glass is A kind of light-weight highstrength building materials and decoration materials with superior performance, such as insulation (cooling), sound absorption, moisture-proof and fireproof. Its operating temperature ranges from minus 196 to 450 degrees.


1.Characteristics of Foam/cellular Glass panel:

 Applicable for both cryogenic and high temperatures.

 Low thermal conductivity but high compressive strength.

 No water absorption ,no permeability ,excellent airtight property.

 Low thermal expansion coefficient and good dimensional stability.

 Noncombustibility,no-aging, and corrosion resistant.

 Nontoxic,harmless,and environmental conservation.

 No mildew growth ,no rat eating ,and preventing from insect pest and microorgansim.

3.Technical Data



Ave.Density

Kg/m3

120

130

140

150

160

180

Ave.Thermal Conductivity

w/(m.k)

0.043

0.044

0.046

0.047

0.048

0.050

Ave.Compressive Strength

Mpa

0.8

1.0

1.2

1.4

1.6

2.0

Water Absorption

Vol%

≤0.5

≤0.5

≤0.5

≤0.5

≤0.5

≤0.5

Service Temp

-268~+480

-268~+480

-268~+480

-268~+480

-268~+480

-268~+480

Lineal Expansion Coefficient

1/

9x10-6

9x10-6

9x10-6

9x10-6

9x10-6

9x10-6





WanMaiDe estabished in 2001, a leading manufacturer and exporter of Glass Wool, Rock Wool, Rubber Foam, Foam Glass,Extrude  Polystyrene/XPS, Phenolic foam board insulation in China. After more than 20 years' development, we totally have 10 producing lines for glass wool insulation,5 producing lines for rock wool insulation and more than 30 producing lines for rubber foam insulation.


We had mad OEM production for WANMAIDE which are popular due to the high quality and competitive price all over the world.
