Heat Insulation Fiber Glass Wool Board

Payment Terms: TT or LC

Ref Price : 1-2 USD/METERS

Supply Capability : 10000 METERS

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Qulck Details

  • Place of Origin:
    Tianjin China (Mainland)
  • Brand Name:
    wmdtrade
  • Type:
    Other Heat Insulation Materials
  • Color:
    Yellow
  • Heat conductivity (w/m. k):
    ≤0.043
  • Density(kg/m3):
    10-92
  • Fire resistance:
    Class A
  • Hydrophobicity:
    ≥98%
  • Highest Working Temperature :
    380℃
  • Use of temperature:
    -120℃-400℃
  • Port:
    Tianjin xingang


Glass wool description:



  Glass wool mainly includes glass wool board, blanket and pipe.They are widely used for insulation, in commercial industries

and residential construction. Glass Wool products have the characteristics of good heat insulation and sound absorption, low construction cost,energy-saving insulation, sound controlling and improving the indoor air quality.The following is Glass Wool Board:



     img src="/10046/common/20190516/2f902211-c06e-4558-9f00-2fa54dc3737a.png" title="" alt=""/>

    Item

    Glass Wool  board

    Density

     10-72kg/m3

    Average fiber diameter

      6um

   Thickness

     20-100mm

    Length

     3-30m

   Width

     1-1.2m

   Highest Usage Temperature

     500

   Heat Conduct Coefficient

     0.043-0.032w/mk

   Hydrophobic

     >98.5

   Incombustibility

    Qualified Grade A

   Color

    Yellow ,White ,Pink

   Port of loading

    Tianjin,China main port




Glass wool construction specifications:



density(kg/m3)

width(mm)

thickness(mm)

length(m)

packing/roll

10-72

600

25-200

3-20

   1 roll

10-72

1100

25-200

3-20

  1roll

10-72

1150

25-200

3-20

  1roll

10-72

1200

25-200

3-20

  1roll

10-72

1200

25-200

3-20

  1roll



Technical Parameters of glass wool construction materials:



item

unit

index

measured value

remarks

bulk density

kg/m3

10-96

10-96

GB/T 13350-2000

average diameter of fibers

m

< 8.0

4.0-6.0

GB/T 13350-2000

moisture resistivity

%

> 98

> 98.5

JISA9512-2000

thermal conductivity

W/m.k

0.049-0.042

0.045-0.032

GB/T 13350-2000

incombustibility


incombustible

up to standard (Grade A)

GB/T 13350-2000

sound absorption coefficient



1.03product reverberation positioning 24kg/m32000HZ

GB/J47-83

Max. working temperature


400

410

GB/T 13350-2000





WanMaiDe estabished in 2001, a leading manufacturer and exporter of Glass Wool, Rock Wool, Rubber Foam, Foam Glass,Extrude  Polystyrene/XPS, Phenolic foam board insulation in China. After more than 20 years' development, we totally have 10 producing lines for glass wool insulation,5 producing lines for rock wool insulation and more than 30 producing lines for rubber foam insulation.

 We had mad OEM production for WANMAIDE which are popular due to the high quality and competitive price all over the world.
