High quality insulation foam rubber tube

Payment Terms: TT or LC

Ref Price : 1-10 USD/PIECE

Supply Capability : 10000 TON

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Qulck Details

  • Place of Origin:
    Tianjin,China
  • Brand Name:
    wanmaide
  • Model Number:
    Rubber tube
  • product material:
    Rubber
  • Product color:
    Black or custom color
  • Rubber sheet thickness:
    ness: 1cm,1.3cm,1.5cm,1.8cm,2cm,2.3cm,2.5cm,2.8cm, 3cm
  • Wide format:
    1 meter, length 10/20 meters can be customized
  • Thermal Conductivity:
    Not more than 0.034 W/m k at 0 °C
  • Wet resistance:
    μ≥5,000
  • Low temperature :
    12
  • Elongation at break:
    36
  • Bending strength:
    52

Construction process



Item

Unit

Technical Index

Standard

Density

Kg/m³

47-50

GB/T 6343

ASTM D1622 or D1667

Oxygen index

%

≥32

GB/T 2406

BS 476 part 7

SDR


≤75

GB/T 8627

Conductivity factor

Average temperature

         -20℃

            0℃

          40℃

w/m•k





≤0.031

≤0.034

≤0.036



GB/T 10294

ASTM C177 or C518

Water vapor permeability

Coefficient

g/(m•s•pa)

≤2.8×10-11





GB/T 17146-1997

ASTM C209

Water vapor permeability

Factor


≤7.0×10³

Water absorption ratio in vacuum

%

≤10

GB/T 17794-2008

Dimension stability 105±3℃,7d

%

≤10

GB/T 8811

Crack resistance

N/cm

≥2.5

GB/T 10808

Compression resilience ratio

Compression ratio 50%

Compression time 72h



%



≥70



GB/T 6669-2001

Anti-ozone

Ozone pressure 202mpa 200h


Not cracking

GB/T 7762

Temperature

-40℃-110℃

GB/T 17794



Product Details

The rubber-plastic insulation material is a closed-cell elastomer material with excellent properties of softness, flexure resistance, cold resistance, heat resistance, flame retardancy, waterproof, low thermal conductivity, shock absorption and sound absorption. Can be widely used in central air conditioning, construction, chemical industry, medicine, textile, metallurgy, shipping, vehicles, electrical appliances and other industries and departments of all kinds of cold and hot medium pipes, containers, can achieve the effect of reducing cold loss and heat loss. Because of its convenient construction, neat and beautiful appearance and no pollution, it is a new generation of high quality insulation material across the century.

High quality insulation foam rubber tubeHigh quality insulation foam rubber tube

High quality insulation foam rubber tube

Product Features

Features: 1. Low thermal conductivity 2. Good flame retardancy 3. Closed-cell foaming, moisture-proof 4. Good seismic performance 5. Easy installation, beautiful appearance


Product Usage

Rubber-plastic sponge insulation material is a soft and high-grade insulation and energy-saving material, which is made of excellent performance NBR and PVC as the main raw materials, together with a variety of high-quality auxiliary materials, foamed by special technology, and contains no chlorofluorocarbons. This product has soft, flex winding resistance, cold resistance, heat resistance, flame retardant, waterproof, low thermal conductivity, shock absorption, sound absorption and other excellent performance. It can be widely used in central air conditioning, construction, chemical industry, medicine, light textile and other industries.





WanMaiDe estabished in 2001, a leading manufacturer and exporter of Glass Wool, Rock Wool, Rubber Foam, Foam Glass,Extrude  Polystyrene/XPS, Phenolic foam board insulation in China. After more than 20 years' development, we totally have 10 producing lines for glass wool insulation,5 producing lines for rock wool insulation and more than 30 producing lines for rubber foam insulation.


We had mad OEM production for WANMAIDE which are popular due to the high quality and competitive price all over the world.
