High temperature resistant fire retardant aluminum foil A grade composite phenolic foam board

Payment Terms: TT or LC

Ref Price : 50-99 USD/METERS

Supply Capability : 10000 METERS

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Quick Details

  • Place of Origin：
    Tianjin China (Mainland)
  • Brand Name：
    wmdtrade
  • Model Number：
    Phenolic insulation board
  • Density：
    40-80kg/cubic meter
  • Thermal Conductivity：
    0.02W/M.K
  • Oxygen Index：
    50%
  • Volume water absorption：
    1.9%(V/V)
  • Degree of compression：
    0.56%
  • Compression creep：
    1.2%
  • Dimensional stability：
    0.3%
  • Operating temperature：
    -250-150℃
  • Port：
    Tianjin xingang

Phenolic foam board Specification:



density >65Kg/m3
Compressive strength 250KPa
Anti-expansion strength Parallel to 270 KPa (30Kg / M3·h), vertical to 200 KPA (30Kg / M 3·h)
Bending strength Horizontal 170KPA (30Kg/M 3·h), vertical 150KPA (30KG/M 3·h)
Thermal Conductivity  0.024W/MK(0oC)
 Water absorption rate  <2% (volume 75MM 3, soak for 24 hours) <3% (volume 75MM 3, soak for 48 hours)
 temperature range  -160 oC—180 oC
Stability and linearity <1% (70 oC, 100% RH, 7 days) <2% (130 oC, 100% RH, 7 days)
 Cell diameter  50-80 (micron)
Combustion performance GB8624-1997B1 class A
 Hygienic Non-toxic




Phenolic foam board Advantage:





1)Fibre-free, clean & safe, non irritant insulation

2). Insulation that acts as a water barrier

3). Highly durable, hail resistant with anti-tear surface

4). Quick & easy to install

5). Anti-fungal & anti-bacterial

6). Resists rodent & insect nesting

7). Excellent Ignitability Rating







WanMaiDe estabished in 2001, a leading manufacturer and exporter of Glass Wool, Rock Wool, Rubber Foam, Foam Glass,Extrude  Polystyrene/XPS, Phenolic foam board insulation in China. After more than 20 years' development, we totally have 10 producing lines for glass wool insulation,5 producing lines for rock wool insulation and more than 30 producing lines for rubber foam insulation.


We had mad OEM production for WANMAIDE which are popular due to the high quality and competitive price all over the world.
