Prime color corrugated roofing sheets factory

Payment Terms: TT or LC

Supply Capability :

Loading Port : TianJin

Price: US 300 USD / Ton

Company Support:
Trade Assurance Payment protection On-time shipment Product quality protection
Payment:

1.Raw Materials:

Thickness	0.15mm-0.8mm
Width	600mm-1250mm
Quality	prime
Zinc coating	Z60-Z275
Spangle	Normal spangle/Small spangle/Big spangle/Zero spangle
Grade	SGCC/DX51D or equivalent standard
Paint	PE; HDP; SMP; PVDF.
Coat	Face two layers paint 20um; back 1 layer paint 5-8um.
Color	RAL color, as request
Packing:	Domestic packing/Export packing

2. Paint:
1. Face paint name -PE; HDP; SIMP; PVDF

2. Face paint detail-Two layers; 20-25um

3. Back paint name-PE grey white color

4. Back paint detail-One layer 5-7um

3. Technical:
1. Forming type-Cold form

2. Machine-Rolling form machine

4. Specification:

Thickness	Normal 0.23mm-0.6mm; min: 0.16mm; max: 1.5mm
Rib height	Depend on model you chose
Wave span	Depend on model you chose
Wave no.	Depend on model you chose
Effective Width	320mm-1025mm
Length	No longer than 11800mm (for transportation purpose)

5. The Available Mode:
